Hardness Testing Machine
Counting upon our competent engineers, we are able to provide Hardness Testers that excel in terms of quality and performance. We offer the Hardness Testers in various models that includes Rockwell Hardness Tester and Vickers Hardness Tester. These Hardness Testers are manufactured at our own unit under strict quality-controlled measures. Known for accurate results, and easy operations, the Hardness Testers have huge market demand. For more details please click on the links given below
| Business Type | Manufacturer, Exporter, Supplier |
| Display Type | Analog |
| Country of Origin | India |
| Brand Name | Aditya Instruments |
| Loads | 500 to 3000 Stages of 250 |
| Initial Load | 250 Kgf |
| Max. test Height | 410mm |
| Depth of Throat | 200mm |
| Max. Depth of Elevating screw below Base | 180mm |
| Size of Base | 370 x 670mm |
| Machine Height | 1127mm |
| Net Weight | 450 Kg |
| Drive Motor | 0.33-415v/p HP |
| Product Code | AI-B 3000 H |
Machine designed with a hydraulic power pack and control circuit for effortless loading unloading operation. A dial gauge in front measures depth of ball penetration. This facilitates production testing within tolerance limits by compression method.
| Business Type | Manufacturer, Exporter, Supplier |
| Brand Name | Aditya Instruments |
| Display Type | Analog |
| Loads | 500 to 3000 Stages of 250 |
| Initial Load | 250 Kgf |
| Max. Test Height | 410mm |
| Max. Depth of Elevating Screw Below Base | 180mm |
| Machine Height | 1127mm |
| Drive Motor | 0.33-415v/p HP |
| Depth of Throat | 200mm |
| Size of Base | 370 x 670mm |
| Net Weight | 450 Kg |
| Origin | India |
| Product Code | AI-B 3000 H |
Machine designed with a hydraulic power pack and control circuit for effortless loading unloading operation. A dial gauge in front measures depth of ball penetration. This facilitates production testing within tolerance limits by compression method.
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Brand Name | Aditya Instruments |
| Loads | 60,100,150 Kgf |
| Initial Load | 10 kgf |
| Max.Test Height | 230mm |
| Depth of Throat | 133mm |
| Max. Depth of Elevating Screw Below Base | 240mm |
| Size of Base (Approx) | 171 x 423mm |
| Machine Height | 635mm |
| Net.Weight (Approx) | 75 Kg |
| Product Code | AI-RAS |
| Business Type | Manufacturer, Exporter, Supplier |
| Brand Name | Aditya Instruments |
| Display Type | Analog |
| Usage | Hardness Testing |
| Material | Mild Steel |
| Initial Load | 10 Kgf |
| Depth of Throat | 150mm |
| Size of Base (Approx) | 210x470mm |
| Net.Weight (Approx) | 137kg |
| Loads | 60,100,150,187.5,250 Kgf |
| Max. Test Height | 295mm |
| Max. Depth of Elevating Screw Below Base | 310mm |
| Machine Height | 845mm |
| Origin | India |
| Product Code | AI-RAB 250 |
| Business Type | Manufacturer, Exporter, Supplier |
| Details |  View |
| Brand Name | Aditya Instruments |
| Total Loads | 5,10,20,30,50 Kgf. |
| Maximum test Height | 200mm |
| Scale Least Count | 0.001mm |
| Diagonal Measuring Range | 0.05 to 0.4mm |
| Throat Depth | 135mm |
| Machine Dimension | L 585 x W 290 X H 860 mm |
| Weight | 70 Kg |
| Power Supply | 220VAC,50HZ,1 Ph |
We, Aditya Instruments are one of the leading manufacturers of Computerized Vickers Hardness Testing Machine is simple & accurate in design. It is appropriate for measuring the hardness of accuracy metallic parts with a wide testing range from soft to hard & their precise results are widely acclaimed. Some of the special features of our tester are :
Small indentation allows testing of precision finished parts.
Thin sheet metals are perfectly tested. Because the applied load is very small.
Motorized loading and unloading cycle.
Internally Built-in projection screen to get exact results.
The same firmness number is acquired on the same specimen, regardless of the load applied.
Extensive testing range, from soft metal such as lead, up to the most solid, like hardened steel.
For world class Vickers Hardness Testing Machine, contact us now.
Features:
- Fully Computerised (PC Based) Vickers Hardness Machine.
- Directand accurate measurementof Vickers Hardness Number using "State of Art"
- Image processing technology.
- High accuracy and repeatability of measurementat all loads.
- Faster measurement yielding to higher productivity.
- Motorised loading and unloading cycle.
- Small loads allow testing of thin sheet metals.
- Wide testing range':from soft metal such as lead up to medium hardened steels.
- Small size of indentation makes ita non-destructive testing on finished components.
- Advanced Window 95/NT based software.
Latest GUI Features :
- Canbe connected to Laptop or Desktop PC. Easyto carry anywhere and handy for use with easy setup.
- Minimum Petnium-ll with 64 MB RAM.
- Windows 98 Operating System. (PC not included in standard scope of supply.)
- One USB 2.0 and one RS232 (serial) interface (9 pin) is required and itis
- Recommended for Laptop to use external USB to serial converter for RS232 interf
PC requirements :
- Online indentation setting and focusing on PC monitor.
- User-friendly software with all help file and Window Features.
- Advance image processing: Algorithms implemented for precise alculation of hardness numbers with various options to cover all ranges of specimen.
